| Video Formats |
- 720P 23.98, 25, 29.97, 50, 59.94, 60
Note: 720p 23.98 (24), 720p 25 and 720p 29.97 require a valid camera source and the use of the Record Type>VFR selection
- 1080i 25, 29.97, 30
- 1080PsF 23.98, 24, 25*, 29.97*
Note: 25 and 29.97 require a valid camera source and the use of the Record Type>PsF selection
- 1080p 23.98, 24, 25, 29.97
- 525i 29.97
- 625i 25
|
| Codec Support |
- Apple ProRes 422
- Apple ProRes 422 (HQ)
- Apple ProRes 422 (LT)
- Apple ProRes 422 (Proxy)
- Avid DNxHD 220x
- Avid DNxHD 145
- Avid DNxHD 36 (Note: Avid DNxHD 36 only provides support for the 1080p format)
|
| Removable
Storage |
- AJA Ki Stor modules – 2 slots with rollover recording
|
| Video Input
Digital |
- SD/HD SDI, SMPTE-259/292/296, 10-bit
- Single Link 4:2:2 (2 x BNC, input selection in software)
- HDMI v1.3
|
| Video Output
Digital |
- SD/HD SDI, SMPTE-259/292/296, 10bit
- Single Link 4:2:2 (1 x BNC)
- HDMI v1.3 Note: HDMI requires 1080i, 720p or 1080p to be active; HDMI does not provide support for PsF
|
| Video Input
Analog |
- SD/HD Component (3 x BNC)
- SD/HD Component (3 x BNC)
- SMPTE/EBU N10, Betacam 525 line, Betacam 525J
- 12-bit A/D, 2x oversampling
- +/- .25 dB to 5.5 MHz Y Frequency Response
- +/- .25 dB to 2.5 MHz C Frequency Response
- .5% 2T pulse response
- <2 ns Y/C delay inequity
or
- Composite (1 x BNC – CVBS on Y)
|
| Video Output
Analog |
- Component (3 x BNC)
- NTSC, NTSCJ, PAL
- HD: YPbPr, RGB
- SD: YPbPr, RGB (component mode)
- SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB
- 12-bit D/A, 8x oversampling
- +/- .2 dB to 5.5 MHz Y Frequency Response
- +/- .2 dB to 2.5 MHz C Frequency Response
- .5% 2T pulse response
- or
- Composite (1 x BNC – CVBS on Y)
- +/- .2 dB to 5.0 MHz Y Frequency Response
- +/- .2 dB to 1 MHz C Frequency Response
- <1% Diff Phase
- <1% Diff Gain
|
| Audio Input
Digital |
- 8-channel, 24-bit SDI embedded audio, 48kHz sample rate, Synchronous
- 2-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous
- 8-channel, 24-bit AES/EBU audio, 48KHz sample rate, Synchronous or Non-synchronous, Internal sample rate Converters (4 x BNC)
|
| Audio Input
Analog |
- 2-channel, 24-bit A/D analog audio, 48kHz sample rate balanced (2 x XLR)
- +24dBu Full Scale Digital
- +/- 0.2dB 20Hz to 20kHz Frequency Response (Note: Line or Mic selection via CONFIG menu parameters
|
| Audio Output
Digital |
- 8-channel, 24-bit SMPTE-259 SDI embedded audio, 48kHz sample rate, Synchronous
- 8-channel, 24-bit HDMI embedded audio, 48kHz sample rate, Synchronous
- 8-channel, 24-bit AES/EBU audio, Synchronous or Non-synchronous, Internal sample rate Converters (4 x BNC)
|
| Audio Output
Analog |
- 2-channel, 24-bit D/A analog audio, 48kHz sample rate, balanced (2 x XLR)
- +24dbu Full Scale Digital (0dbFS)
- +/- 0.2db 20 to 20kHz Frequency Response
- Stereo unbalanced headphone (1 x 3.5mm mini jack)
|
| Timecode |
- SDI RP188/SMPTE 12M via SDI BNC
- HDMI (when used with compatible cameras)
- LTC Input (1 x BNC)
- LTC output (1x BNC) (Note: active during playback not during record or EE)
|
| Reference Input |
- Analog Color Black (1V) or Composite Sync (2 or 4V)
- Looping, non-terminating
|
| Network
Interface |
- 10/100/1000 Ethernet (RJ-45)
- Embedded web server for remote control
|
| Machine
Control |
- Rs-422, Sony 9-pin protocol (via DB-25 breakout cable or optional KLHi-Box)
- 9-pin D-connector pinout is as follows:
| 1 |
GND |
| 2 |
RX- |
| 3 |
TX+ |
| 4 |
GND |
| 5 |
No Connection |
| 6 |
GND |
| 7 |
RX+ |
| 8 |
TX- |
| 9 |
GND |
| Shell |
GND |
|
| User Interface |
- 2 x 20 character display, with dedicated buttons
|
| Power |
- 100-240 VAC 50/60Hz (Dual, redundant power supplies), 40W typical
|
| Size |
- Width 48.26cm x Depth 37.74cm (front panel to the back of the deepest connector) x Height 4.45cm
|
